32P TYCO AMP TE PTFE Insulated Cable 1318747 - 1 UL1332 - 22AWG

Ask Lasest Price
Brand Name :	TYCO/TE/AMP
Model Number :	13187470-1+1123343-1+UL1332-22AWG
Certification :	UL/CAS/ROHS/RECHA/ISO9001/TS16949/IPC/WHMA-A-620
Price :	Negotiable
Payment Terms :	Western Union, MoneyGram
Supply Ability :	100000PCS/D

Add to Cart

Product Details
Company Profile

32P TYCO AMP TE PTFE Insulated Cable 1318747 - 1 UL1332 - 22AWG

TE 1123343 - 1 New energy and 32P 1318747 - 1 wire harness for Industrial

Product Description

TE 1123343 - 1 New energy and 32P 1318747 - 1 wire harness for Industrial
Categories	Connectors, Interconnects Rectangular Connectors - Housings
Manufacturer	TE Connectivity AMP Connectors
Series	.025
Part Status	Active
Connector Type	Plug
Contact Type	Female Socket
Number of Positions	32
Pitch	0.087" (2.20mm)
Number of Rows	2
Row Spacing	0.118" (3.00mm)
Mounting Type	Free Hanging (In-Line)
Contact Termination	Crimp
Fastening Type	Locking Ramp
Color	Natural

TYCO AMP TE Automotive Termial harness 1318389-1 and 1123343-1 UL1332-22AWG PTFE Cable Custom processing

1473672 - 1	CONN PLUG HOUSING FEMALE CRIMP	Plug	Female Socket	4	0 . 087 " ( 2.20mm )
1379658 - 1	4W RCPT HSG CODING 1 BLAC	Plug	Female Socket	4	0 . 087 " ( 2.20mm )
1473672 - 2	025 PLUG ASSY	Plug	Female Socket	4	0 . 087 " ( 2.20mm )
1318774 - 1	025 ECU PLUG HSG ASSY 12P	Plug	Female Socket	12	0 . 087 " ( 2.20mm )
1318386 - 1	025 ECU PLUG HSG ASSY 16P	Plug	Female Socket	16	0 . 087 " ( 2.20mm )
1376352 - 1	025 I/O PLUG HSG ASSY 8P	Plug	Female Socket	8	0 . 087 " ( 2.20mm )
1318917 - 1	025 ECU PLUG HSG ASSY 24P	Plug	Female Socket	24	0 . 087 " ( 2.20mm )
1318389 - 1	025 ECU PLUG HSG ASSY 40P	Plug	Female Socket	40	0 . 087 " ( 2.20mm )
1318747 - 1	025 ECU PLUG HSG ASSY 32P	Plug	Female Socket	32	0 . 087 " ( 2.20mm )
1565380 - 1	025 28POS PLUG ASSY	Plug	Female Socket	28	0 . 087 " ( 2.20mm )
1379659 - 1	8W PLUG HOUSING ASSY BLAC	Plug	Female Socket	8	0 . 087 " ( 2.20mm )
1473793 - 1	025 IDC 8POS CAP ASSY W TO W	Receptacle	Tab	8	0 . 087 " ( 2.20mm )
1565894 -1	CONN RCPT HSNG 12POS FREE HANGNG	Receptacle	Female Socket	12	0 . 087 " ( 2.20mm )
1473750 - 1	025 20POS CAP ASSY W TO W	Receptacle	Tab	20	0 . 087 " ( 2.20mm )

UL standard internal wiring
UL1007 Hook-up Wire
UL1015 Hook-up Wire
UL1061 Hook-up Wire
UL1185 Single Conductor Shielded Cable
UL1316 Reinforced Hook-up Wire
UL1330 FEP Insulated Wire
UL1430 Crosslinked PVC Insulated Wire
UL1452 Reinforced Hook-up Wire
UL1533 Single Conductor Shielded Cable
UL1569 Hook-up Wire
UL1571 Hook-up Wire
UL1672 Reinforced Hook-up Wire
UL10064 FEP Insulated Wire
UL10086 High Temperature Resistant Hook-up Wire
UL10097 Crosslinked PVC Insulated Wire
UL10272 Hook-up Wire
UL10308 High Temperature Resistant Hook-up Wire
UL2464 Multi-Conductor Shielded Cable
UL2468 Flat Ribbon Wire
UL2509 Multi-Conductor Cable
UL2517 Multi-Conductor Shielded Cable
UL2547 Multi-Conductor Shielded Cable
UL2552 Multi-Conductor Shielded Cable
UL2576 Multi-Conductor Cable
UL2586 Multi-Conductor Cable
UL2651 Flat Ribbon Wire
UL2725 Multi-Conductor Shielded Cable
UL2835 Multi-Conductor Shielded Cable
UL2854 Multi-Conductor Shielded Cable
UL2919 Low Voltage Multi-Conductor Shielded Cable
UL20276 Multi-Conductor Shielded Cable
UL20379 Multi-Conductor Shielded Cable
UL21149 Multi-Conductor Shielded Cable
UL21520 Multi-Conductor Cable
UL3443 Hook-up Wire

UL halogen-free wire
UL11027 Hook-up Wire
UL10983 Single Conductor Shielded Cable
UL10982 Hook-up Wire
UL10981 Hook-up Wire
UL10984 Reinforced Hook-up Wire
UL10986 Single Conductor Shielded Cable
UL10987 Hook-up Wire
UL11025 Hook-up Wire
UL11028 Hook-up Wire
UL11029 Hook-up Wire
UL11045 Reinforced Hook-up Wire
UL11047 Reinforced Hook-up Wire
UL21451 Double Shielded Cable
UL21452 Double Shielded Cable
UL21455 Multi-Conductor Shielded Cable
UL21456 Multi-Conductor Shielded Cable
UL21457 Multi-Conductor Shielded Cable
UL21458 Flat Ribbon Wire
UL21461 Multi-Conductor Shielded Cable
UL21474 Multi-Conductor Shielded Cable
UL21476 Multi-Conductor Shielded Cable
UL21515 Flat Ribbon Wire
UL21517 Multi-Conductor Shielded Flat Ribbon Wiree

Industrial electric wire

Flexible Single Core Cable
Flexible Multi-core Torsion Cable
Flexible Multi-core Shielded/Non-Shielded Control Cable

VDE standard wire

LifY Single Core,extra fine wires with highest flexibility
LIYY-Command Cable (Style 2464/300 V, (80°C)
LIYY-TP-Command Cable-Twisted (Style 2464/300 V, (80°C)
LIYCY-Shielding Command Cable (Style 2464/300 V, (80°C)
LIYCY-TP-Shielding Command Cable-Twisted (Style 2464/300 V, (80°C)

Automotive wire

FLRY-A Automotive Wire Series
FLRY-B Automotive Wire Series
FLRYW Automotive Wire Series

TWP Automotive Wire Series
TXL Automotive Wire Series
GXL Automotive Wire Series
AVS Automotive Wire Series
AVSS Automotive Wire Series

Packaging & Shipping

Export cartons
(406mm*306mm*250mm)
