Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A

Ask Lasest Price
Brand Name :	TE/TYCO/AMP
Model Number :	5-747912-2
Certification :	UL/CAS/ROHS/RECHA/ISO9001/TS16949/IPC/WHMA-A-620
Price :	USD0.1-1000/PCS
Payment Terms :	Western Union, MoneyGram
Supply Ability :	10000PCS/D

Add to Cart

Product Details
Company Profile

Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A

TE solding D-SUB connector wire harness 5-747912-2 / LIYCY PVC cable Custom customization

Documents & Media

cable use LIYY/LIYCY/UL2464/2517/2586,,,,,,

cable Jacket use PVC/PU/TPE/PUR

Plug	RECEPTACLE
747904 - ( )	747905 - ( )	9
747908 - ( )	747907 - ( )	15
747912 - ( )	747913 - ( )	25
757916 - ( )	747917 - ( )	37

Datasheets	747912
Product Training Modules	AMPLIMITE D - Sub Connectors
RoHS Information	5 - 747912 - 2 Statement of Compliance
RoHS Information	RoHS 2 Statement
Featured Product	AMPLIMITE D - Subminiature Connectors
Mfg CAD Models	5 - 747912 - 2 . pdf
PCN Design / Specification	Amplimite Solder Cup Connectors 17 / Feb / 2014
PCN Design / Specification	Multiple Drawings Metric Conversion Correction 08 / Jul / 2015
Online Catalog	AMPLIMITE HD - 20 Series

Product Attributes	Select All
Categories	Connectors , Interconnects
Categories	D - Sub Connectors
Manufacturer	TE Connectivity AMP Connectors
Series	AMPLIMITE HD - 20
Packaging	Tray
Part Status	Active
Connector Style	D - Sub
Connector Type	Plug , Male Pins
Number of Positions	25
Number of Rows	2
Shell Size , Connector Layout	3 ( DB , B )
Contact Type	Signal
Mounting Type	Free Hanging ( In - Line )
Flange Feature	Housing / Shell ( Unthreaded )
Termination	Solder Cup
Features	Grounding Indents
Shell Material , Finish	Steel , Tin Plated
Contact Finish	Gold
Contact Finish Thickness	8µin ( 0 . 20µin )
Ingress Protection	-
Material Flammability Rating	UL94 V - 0
Operating Temperature	- 55 °C ~ 105 °C
Voltage Rating	250V
Current Rating	3A
Color	Black
Contact Form	-
Housing Material	Polybutylene Terephthalate ( PBT ) , Glass Filled
Wire Gauge	-
Contact Material	Brass
Backset Spacing	-

We can provide the service.

1: Quick response

2: Professional services
A:Crimping.
B:Soldering.
C:Harness molding-(PVC/PE/TPE/TPU and so on )
D:IDC.
E:On the surface of the metal coating(TPE/TPU/PVC and so on).
F:Harness assembly,Control cabinet assembly .
G:Connector customization and injection molding .
3: Localization, cost reduction (customer approval)

4: Precise logistics

5: The purchase of globalisation

6: We can provide the file:
A:product drawing, B:material certificate ,
C: Inspection report, D: the HS code.
If you need certificate of origin,Control plant,IMDS and so on , please let us know

Q1: What's your guarantee?
A: All our products have 1 year guarantee, if any quality problem can contact us.
Q2: What's your delivery time ?
A: The delivery time is 5-15 working days. The specific delivery time depends on the items and the quantity of your order.
Q3: What's your minimum order quantity?
A: For bulk order, the MOQ is 100 pcs.

Q4: Can you supply the sample?
A: We can supply samples to check the quality before bulk order. But the price will be sample price not wholesale price.

Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q6.Product standards
A:IPC/WHMA-A-620B( Requirements and Acceptance for Cable and Wire Harness Assemblies )

Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A

D - SUB - 9PIN Male

D - SUB - 15PIN Male

D - SUB - 25PIN Male

D - SUB - 37PIN Male

Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A

D - SUB - 9PIN Female

D - SUB - 15PIN Female

D - SUB - 25PIN Female

D - SUB - 37PIN Female

Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A

HDB - 15PIN Male

HDB - 26PIN Male

HDB - 44PIN Male

HDB - 50PIN Male

Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A

HDB - 15PIN Female

HDB - 26PIN Female

HDB - 44PIN Female

HDB - 50PIN Female

Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A

HDB - 62PIN Male

HDB - 78PIN Male

HDB - 62PIN Female

HDB - 78PIN Female

Soldering TYCO Wiring Harness AMP TE 5 - 747912 - 2 Single Wire BK 250A
