    Bayonet Type LED Wire Connectors Front Panel Mount Lock TVR 1.25 - 5 Add JST XAP - 3V - 1

    Ask Lasest Price
    Brand Name : Customized
    Model Number : Cha
    Certification : UL/ROHS
    Price : USD30-1000/PCS
    Supply Ability : 1000PCS/D
    • Product Details
    • Company Profile

    Bayonet Type LED Wire Connectors Front Panel Mount Lock TVR 1.25 - 5 Add JST XAP - 3V - 1

    LED Connector Front Panel Mount lock bayonet type , solder add JST VHR-8N Soldering Wiring Harness / PVC / BK


    Specifictations


    Number of Contacts233918243+93+11
    Wire Gauge4.0mm 2 ( 12AWG )8.4mm2 ( 8AWG )0.75mm2 ( 18AWG )

    0.3mm2

    ( 22AWG )

    		2.5mm2 + 0.2mm2 ( 12AWG + 24AWG )
    Panel ThicknessMax . 5.0mmMax . 2.2mm
    Environmental ProtectionIP67
    Mechanical Life500 mating cycles
    Operating Temperature- 45 ℃ ~ 105 ℃
    Voltage Rating300V300V300V125V125V300V300V
    Rated Current ( 40 ℃ )20A20A50A5A5A20A + 5A20A + 5A

    TVR / VF

    Ring Terminals

    Electrolytic copper

    Tin plated

    Easy entry

    P.V.C.insulation

    NO:E185793(N)Series VF1.25 VF5.5


    PART NOTYPEWIRE RANGEØ DHFBØ d2LCOLORMaximum currentCrimping Tools
    AWG / MCMmm2
    001010.75 - 322 - 160.2 - 1.03.59.64.35.53.216.5RED10AYYT - 1 YYT - 7 2026NJ
    001020.75 - 46.684.320.2
    001030.75 - 56.685.320
    001041.25 - 3S22 - 160.5 - 1.6410.64.35.53.217.719A
    001051.25 - 34.35.53.717.7
    001061.25 - 3M16.66.63.220.5
    001071.25 - 3M6.66.63.720.5
    001081.25 - 47.384.321.9
    001091.25 - 4M6.66.64.320.5
    001101.25 - 57.385.321.9
    001111.25 - 611.411.66.427.8
    001121.25 - 811.411.68.427.8BLUE27A
    001132 - 316 - 141.0 - 2.64.710.77.78.53.222.7
    001142 - 3M6.36.63.720.3
    001152 - 47.78.54.322.7
    001162 - 4M6.36.64.320.3
    001172 - 57.29.55.322.7
    001182 - 611126.427.7
    001192 - 811128.427.7
    001202 - 1013.913.610.531.4
    001213.5 - 412 - 102.6 - 4.65.813.58.29.54.326.5YELLOW37A
    001223.5 - 58.29.55.326.5
    001233.5 - 68.5126.428
    001245.5 - 312 - 104.6 - 6.66.213.68.29.53.726.648A
    001255.5 - 48.29.54.326.6
    001265.5 - 58.29.55.326.6
    001275.5 - 613126.432.6
    001285.5 - 813.7158.434.8
    001295.5 - 1013.71510.534.8

    JST XAP
